Product Overview

The KR‑1717A benchtop halogen moisture tester applies loss‑on‑drying thermogravimetric principle for fast moisture‑content determination. Equipped with high‑performance halogen heating lamp and imported precision weighing sensor, the unit evaporates water content inside test samples by rapid uniform heating. It continuously tracks weight variation during drying process and instantly calculates moisture percentage as well as solid residue values.

Compared against traditional constant‑temperature oven methods, this benchtop instrument drastically cuts test duration from several hours down to a few minutes. It supports automatic test termination upon drying completion, requires no complex auxiliary supplies, and delivers stable repeatable outcomes for granular, powdered, paste and flake‑shaped specimens. Widely deployed across food‑processing, pharmaceutical, plastic‑polymer, grain‑feed, chemical and textile‑material QC laboratories.

Core Product Competitive Advantages

1. High‑precision imported weighing sensing module High‑resolution weighing sensor delivers moisture readability of 0.001 % and weight resolution down to 0.01 g. Anti‑drift algorithm suppresses reading deviations induced by ambient temperature fluctuation and air convection, securing trustworthy measurement data for routine quality‑control workflows.
2. Uniform halogen radiant heating system Halogen lamp provides fast‑ramp, evenly‑distributed thermal radiation. Heating chamber adopts durable stainless‑steel inner shell, which resists high‑temperature corrosion and facilitates post‑test wiping‑cleaning. Operators adjust target drying temperature flexibly for heat‑sensitive or high‑moisture test‑substances.
3. User‑friendly standalone benchtop operation Ready‑to‑use right after unboxing without extra installation or commissioning. Intuitive keypad‑driven interface minimises operator‑training requirements. Multiple real‑time metrics are displayed simultaneously: moisture value, residual solid content, sample mass, test runtime and heating temperature. Auto‑alert signal triggers once measurement finishes.
4. Built‑in data output expandability Supports connection to external PC or thermal printer for exporting, storing and printing complete test records. Final stable moisture reading can be automatically locked upon test completion, convenient for lab‑report compilation and batch‑data archiving.
5. Compact rugged table‑top cabinet design Light‑weight compact footprint occupies limited bench‑top real‑estate. Integrated wind‑shield assembly shields internal weighing chamber from ambient airflow interference, improving stability during specimen‑heating cycles. Wide working‑temperature range adapts to diverse factory‑lab environmental conditions.

Complete Technical Parameter Table

Parameter Item	KR‑1717A Standard Specification
Moisture Measuring Readability	0.001 %
Moisture Content Measuring Range	0 ~ 100 %
Weighing Capacity	3 ‑ 110 g
Minimum Weight Readout	0.01 g
Drying Temperature Scope	Room temperature ~ 199 ℃
Simultaneous Display Parameters	7 groups (moisture %, solid content %, sample weight, test time, temperature etc.)
Operating Ambient Temperature	‑5 ℃ ~ 50 ℃
Power‑Supply	AC 220 V ±10 %, 50 Hz ±1 Hz
Overall Outer Dimension(L×W×H)	337 × 215 × 334 mm
Complete‑Machine Net‑Weight	3.7 KG

Standard Complete Test Operating Workflow

1. Pre‑Test Preparation Place instrument on vibration‑free horizontal lab bench. Complete power‑on and allow sufficient warm‑up period. Perform zero‑point calibration before starting batch testing. Prepare sample trays and target test specimens (powder, granule, paste or fragments). Set target drying temperature via front‑panel keypad according to material thermal‑resistance property.
2. Sample Loading Place empty sample pan onto weighing platform, execute tare‑zero operation. Dispense appropriate quantity of prepared sample evenly across tray surface. Close the heating‑chamber cover securely.
3. Initiate Moisture‑Determination Test Press start‑test key. Halogen heating lamp activates, sample is heated continuously. Instrument keeps tracking real‑time weight loss and dynamically updates moisture‑content figures on display screen.
4. Automatic Termination & Result Recording When weight change falls below preset threshold, the system automatically stops heating and locks final moisture‑percentage result. Record readings manually or export datasets via printer / PC communication port. Solid‑content ratio can also be retrieved from display panel.
5. Post‑Test Tidying Open heating‑chamber lid after inner assembly cools down. Discard dried sample residue, wipe sample pan clean for next‑round measurement. Shut‑off main power‑supply if no further testing tasks remain. Carry‑out periodic balance calibration to sustain measuring‑accuracy.



Wide Industrial Application Scenarios

Food & Grain Processing Enterprises

Fast moisture‑check for grains, cereals, snacks, seasoning, meat‑products and dehydrated food‑stuffs for incoming‑material inspection and production‑line quality‑monitoring.

Pharmaceutical & Chemical‑Material R‑D Departments

Moisture‑content analysis for pharmaceutical raw‑materials, polymer‑pellets, resin, powder‑chemicals and granular chemical intermediates.

Plastic & Rubber‑Product Manufacturers

Water‑content testing for plastic particles, master‑batch and rubber‑compounds, helping prevent bubbling and surface‑defects during moulding‑process.

Feed & Agricultural‑Product Factories

Rapid‑moisture evaluation for feed raw‑stock, seeds and agricultural by‑products.

Paper‑Making & Textile‑Material Laboratories

Moisture‑rate measurement for paper pulp, textile‑fibres and various fibrous raw‑materials.

Third‑Party Accredited‑Testing‑Organizations

Conduct rapid moisture‑determination for multi‑category samples and generate documented test‑records for quality‑audit requirements.

Standard Factory‑Full‑Delivery Kit

1. KR‑1717A halogen rapid moisture‑analyzer main benchtop unit
2. Set of disposable / reusable sample trays
3. Anti‑wind shield assembly
4. Built‑in halogen heating‑lamp module
5. Power‑supply connecting‑cable
6. Multilingual printed‑operation‑manual
7. Factory‑issued performance‑inspection‑certificate

Optional spare‑parts & custom‑options: replacement halogen lamp, external thermal printer, PC data‑export software kit, special‑voltage power‑supply‑adaptation.

Global Distributor & After‑Sales‑Support

We provide remote‑one‑on‑one operational guidance covering temperature‑parameter setup, tare‑calibration steps, sample‑loading best‑practices and routine preventive‑maintenance. Spare‑parts stock includes halogen heating‑bulbs, sample‑tray accessories and sensor‑related spare‑parts. Bulk‑order customers can apply for custom‑power‑supply‑voltage variants for overseas‑market deployment. Regional‑exclusive‑agent privileges contain priority‑production‑scheduling, OEM private‑branding‑services and complete‑set high‑definition product‑marketing‑image‑resources.

Product‑Banner‑Marketing‑Slogan

KR‑1717A Halogen Rapid Moisture Analyzer | High‑Precision Loss‑On‑Drying Moisture‑Balance For Food‑Plastic‑Pharm‑Grain‑Lab‑QC‑Testing

Core‑Feature‑Labels‑For‑Product‑Images

Halogen‑Heating‑Moisture‑Analyzer, 0.001%‑Moisture‑Readability, 0‑100%‑Measuring‑Range, 3‑110g‑Weighing‑Capacity, Room‑Temp‑199℃‑Adjustable‑Drying‑Temp, Loss‑On‑Drying‑Principle, Auto‑Stop‑At‑Test‑Completion, Real‑Time‑Multi‑Parameter‑Display, Anti‑Wind‑Shield‑Design, Stainless‑Steel‑Heating‑Chamber, PC‑Printer‑Data‑Export, Compact‑Benchtop‑Layout, Food‑Pharm‑Plastic‑Grain‑Feed‑Moisture‑QC‑Measurement

Safety‑Operation‑Reminder

Do not touch heating‑chamber interior and sample‑pan immediately after measurement to avoid high‑temperature scald risk. Ensure instrument completes adequate warm‑up before formal testing. Keep weighing‑chamber free of sample‑dust contamination. Execute periodic balance calibration to guarantee reliable test‑readings. Ensure reliable equipment‑grounding before power‑on.
