Product Overview

The KR‑408A handheld inductive paper moisture tester adopts high‑frequency electromagnetic sensing principle for non‑destructive rapid moisture detection. Integrated sensor‑and‑host design eliminates sample cutting or damaging operations. Users simply place the sensing head against paper‑based materials to get instant moisture‑content readings.

Six‑selectable calibration gears adapt for diverse substrates including plain paper, cardboard, corrugated board, carton boxes and pulp sheets. Compact handheld form factor supports on‑spot production‑line spot‑checks, warehouse incoming‑goods sampling and lab‑quick screening. Widely utilised within pulp‑and‑paper mills, printing workshops, packaging‑manufacturing plants and quality‑inspection departments for real‑time moisture monitoring during manufacturing, storage and material‑receiving workflows.

Core Product Competitive Advantages

1. Non‑Destructive High‑Frequency Inductive Sensing Technology High‑frequency electromagnetic field detects internal moisture without piercing or destroying paper samples. No need for specimen preparation; complete measurement by direct surface contact, greatly boosting on‑site inspection efficiency.
2. Six‑Gear Material‑Matching Calibration Settings Multi‑position adjustment knob provides six calibration gears to match different paper grades, thickness and pulp types. Effectively reduces material‑property‑caused measuring deviation and delivers stable, trustworthy readings for varied paper‑board products.
3. Fast‑Response Digital LCD Readout 3½‑digit clear LCD display refreshes measured value within merely 1 second. Features zero‑point correction button for quick baseline reset before batch‑testing, simple to operate even for less‑experienced field‑operators.
4. Built‑In Wide‑Range Automatic Temperature Compensation Integrated temperature‑compensation module works across‑10 ℃ ~ +100 ℃. It offsets reading drift induced by ambient‑temperature fluctuation, securing measuring precision under varied factory‑site environmental‑conditions.
5. Ultra‑Portable Rugged Hand‑Held Construction Light‑weight 200‑gram body with pocket‑friendly dimensions. Powered by standard 9V laminated battery. Comes with protective hard‑shell carry‑case for safe transport and storage, ideal for frequent moving between production‑lines and warehouse zones.

Complete Technical Parameter Table

表格

Standard Complete Test Operating Workflow

1. Pre‑Test Preparation Take the moisture meter out of protective carry‑case. Install qualified 9 V battery. Power‑on device, perform zero‑calibration with ZERO button according to operating hints. Select proper material‑calibration gear matching the target paper‑board type.
2. On‑Site Specimen Measurement Lay paper / cardboard sample flat. Place the instrument’s inductive sensing head fully onto the material surface, keep steady contact without tilting.
3. Read Moisture‑Content Data Stable moisture‑percentage value appears on LCD within one second. Record reading. For batch‑assessment, take multiple measuring points across different positions of sheet or stack to get representative average‑value.
4. Switch Gear For Different‑Grade Materials When changing to another paper‑board variety, rotate selector knob to corresponding calibration‑gear and re‑check zero‑point before continuing measurements.
5. Post‑Operation Storage Power‑off the instrument after finishing inspection. Remove battery for long‑time idle storage. Wipe sensing‑head surface clean, place unit back into shock‑proof carry‑case.

Wide Industrial Application Scenarios

Pulp‑Paper Manufacturing Plants

On‑line and off‑line spot moisture‑check for base‑paper, finished‑paper and pulp sheets; monitor moisture‑level to avoid paper brittleness, static‑electricity and dimensional‑deformation issues.

Printing Enterprises

Raw‑paper incoming‑batch moisture inspection; prevent printing‑defects such as slow‑ink‑drying, paper‑wrinkle and static‑caused mis‑registration.

Corrugated‑Carton & Packaging Factories

Rapid moisture‑detection for liner‑board, corrugating‑medium and finished cartons; control product quality for die‑cutting, folding and gluing processes.

Paper‑Material R&D Departments

Fast comparative moisture screening for new‑formula paper‑board samples.

Third‑Party Accredited‑Testing‑Organizations

Field‑oriented non‑destructive moisture spot‑sampling for paper‑related material quality‑audit projects.

Standard Factory‑Full‑Delivery Kit

1. KR‑408A inductive‑type paper moisture‑meter main‑unit
2. 9 V (6F22) laminated battery
3. Shock‑resistant hard plastic carry‑case with foam inner lining
4. Multilingual printed‑operation‑manual
5. Factory‑issued performance‑inspection‑certificate

Global Distributor & After‑Sales‑Support

We supply remote‑one‑on‑one usage guidance covering gear‑selection, zero‑point calibration and battery‑maintenance. Spare‑parts include replacement 9V batteries. Bulk‑order customers can request custom‑voltage related accessories. Regional‑exclusive‑agent privileges contain priority‑production‑scheduling, OEM private‑branding‑services and complete‑set high‑definition product‑marketing‑image‑resources.

Product‑Banner‑Marketing‑Slogan

KR‑408A Inductive‑Type Paper Moisture Meter | Non‑Destructive Hand‑Held Tester For Paper‑Cardboard‑Corrugated‑Board On‑Site Moisture‑Measurement

Core‑Feature‑Labels‑For‑Product‑Images

Non‑Destructive Inductive‑Detection | Six‑Material‑Calibration‑Gears | 1‑Second Fast‑Response | 3½‑Digit LCD Display | Auto‑Temperature‑Compensation | Zero‑Point Calibration | Ultra‑Light‑Weight Hand‑Held | Equipped Protective Carry‑Case

Safety‑Operation‑Reminder

Do not expose instrument to heavy‑impact or high‑humidity corrosive‑environment. Remove battery if the device will stay unused for extended periods. Keep inductive sensing‑head clean, avoid scratching the sensing surface.
